The KH-iES715-32 edge AI server from the advanced Scandium series (known as AI Qube) is a highly intelligent, compact, enterprise-grade solution for real-time metadata extraction and deep-learning processing at the network edge.
-
Function
AI ISP
-
Metadata
Metadata
-
Function
Face Detection
Overview
The KH-iES715-32 edge AI server from the advanced Scandium series (known as AI Qube) is a highly intelligent, compact, enterprise-grade solution for real-time metadata extraction and deep-learning processing at the network edge. Its advanced Intel processor with a dedicated neural processing unit (NPU) delivers impressive processing power of up to 99 TOPS for running multiple AI functions in parallel. It handles several analytics at the same time, including license plate recognition (LPR), face recognition, perimeter protection, behavior analysis and HSE safety monitoring, and sends its results to the workstations. Its unique engineering packs everything into an ultra-compact, tool-less 0.48-liter chassis with a highly durable body, certified to MIL-STD-810H. With 32 GB of RAM, a high-speed 2.5GbE LAN port, Wi-Fi 7 support and top-level cybersecurity from a TPM 2.0 hardware chip and the vPro security architecture, this server is the AI core of modern surveillance projects.
System Architecture
- Processor
- Intel®️ Advanced AI Processor (Featuring Dedicated NPU)
- AI Computing Power
- Up to 99 TOPS (Tera Operations Per Second)
- Graphics
- Intel®️ Arc™️ Graphics (Optimized for Edge AI Inference)
- Memory
- 32GB DDR5 High-Speed Memory
- Storage
- 256GB PCIe Gen4 NVMe SSD (512GB / 1TB Optional Upgrade By Order)
- Hardware Security
- TPM 2.0, Intel®️ vPro™️ Platform Support
- Operating System
- Embedded Windows
- Installed Software
- AI VMS PLUS
AI Channel Capacity
- Face Recognition
- (via License Upgrade) Up to 8 Channels
- Perimeter Protection
- (via License Upgrade) Up to 16 Channels
- Advanced HSE/
Behavior - Up to 4 Channels (Requires Pro Analytics License)
Network
- LAN
- 1× RJ-45 2.5 Gigabit Ethernet
- Wireless Network
- Bluetooth 5.4 Wi‑Fi 7 (BE201) (Optional)
General
- Power Supply
- 19V DC-in (120W AC Adapter Included)
- Power Consumption
- Max 40W (cTDP) - Ultra High Energy Efficiency
- Form Factor
- Rack or Tower
- Dimensions
- 117x 112x 54mm
- Installation
- Desktop / VESA Mount (Bracket Included)
- Operating Temp
- 0°C ~ 40°C
- Storage Temp
- -40°C – 65°C
- Humidity
- 0% ~ 92% (Non-condensing)
- Certifications
- CE, FCC, MIL-STD-810H, RoHS
AI Video Analytics
- Perimeter Security
-
Abandoned Object, Area Entry/
Exit, Intrusion, Line Crossing, Loitering - HSE & Safety
-
Fire/
Smoke, Gas Leak Detection, Hard Hat, High-Visibility Vest - Security
- Gun Detection, Knife Detection
- Behavioral Analysis
-
Fall Detection (Man-Down)
Fight/
Violence Running Sleeping on Duty - Traffic & Vehicle
-
ANPR/
LPR, Congestion, Forklift Speeding, Illegal Parking
I/O Interfaces
- Video Output
- 2× HDMI 2.1 (Up to 4K @ 60Hz) 2× Thunderbolt™ 4 (Supports DisplayPort 2.1)
- USB (Front)
- 1× USB 3.2 Gen 2x2 (Type-C) 2× USB 3.2 Gen 2 (Type-A)
- USB (Rear)
- 1× USB 3.2 Gen 2 (Type-A) 1× USB 2.0 (Type-A)
- Audio
- Up to 7.1 multi-channel digital audio on HDMI and Thunderbolt ports
Downloads
Documentation
-
KH-iES715-32
Compare products
Compare this product with similar products
Please wait
Frequently asked questions: Software
Answers to common questions about this product line, from the KDT Help Center.
How can I connect to my cameras and NVR remotely and securely?
There are three ways to reach devices from outside, and they differ mostly in security. A VPN into your own network is the most secure and works for the VMS, the web page and the app alike; P2P (a cloud service) is the simplest for phones, because the device connects out to the cloud service and as a rule needs neither a public IP nor router configuration; port forwarding with DDNS is the most fragile and leaves the largest attack surface open. Use a VPN for administrators and VMS clients, use P2P for occasional phone viewing if you trust the manufacturer's cloud service, and treat port forwarding as a last resort. The specification tables of KDT NVRs and cameras list P2P and DDNS among their supported protocols.
Which software does KDT offer, and what is each program for?
For video management, KL-VMS+ (VMS Plus) is KDT's licensed VMS for large projects with several servers; for analytics, KL-PRS reads license plates and KL-FRS recognizes faces. For everyday work with KDT NVRs and cameras, the product specification tables list the KDT CMS/VMS Windows software and apps for Android and iOS. The download center of this website adds device-search tools, KDT Player and KDT Desk, the remote-support program.
What is a VMS, and how is it different from the NVR's web page and the mobile app?
A VMS (video management software) is installed on a PC or server and manages many cameras and NVRs from one place, with separate users and permissions, alarm rules, maps, several monitors and analytics. The NVR's web page is for configuring and viewing that single device, and the mobile app is for quick live view and playback. Supported browsers depend on the model: the specification tables list Chrome, Edge, Firefox and IE for most models and IE only for some.
What is the difference between CMS and VMS?
CMS (central management software) is usually the client program that comes with recorders: it connects to several devices and provides live view, playback and export. A VMS is a fuller platform that adds recording servers, multi-server and multi-site operation, user roles, alarm rules and analytics. Vendors do not always keep the two names apart, which is why the specification tables of KDT NVRs simply list 'KDT CMS/VMS'; for the fuller platform, see the KL-VMS+ datasheet.
Which software suits my project: the web page, KDT VMS or KL-VMS+?
For one site with a single NVR and a few viewers, the web page and the mobile app are enough and nothing has to be installed. For several recorders or a control room with several monitors, use the Windows KDT VMS; its manual states that it can show 128 cameras across several monitors. For projects with several sites, user roles, maps, alarm rules, or integrated plate and face recognition, choose KL-VMS+, which according to its datasheet has no limit on the number of servers or users.
