سوئیچ کی دی تی مدل KP-0804H5SM
| Interfaces | |
| Total Port | 12 Ports |
| POE Output (Max) | 200 Watt |
| POE Port Control | Realtek 8238B/8239B |
| Fast RJ45 POE Port | N/A |
| Gigabit RJ45 POE Port | 8 Ports Port 1*4 AT (Up to 30W) Port 5*8 BT (Up to 90W) |
| Fast RJ45 Uplink Port | N/A |
| Gigabit RJ45 Uplink Port | N/A |
| 10 or 2.5 Gigabit SFP Uplink Port | 4 |
| Combo Uplink Port | N/A |
| Network Performance | |
| Standard | IEEE802.3x, IEEE802.3u, IEEE802.3az, IEEE802.3ab, IEEE802.3af, IEEE802.3at (Up to 30Watt), IEEE802.3bt |
| Protocols | CSMA/CD |
| Router | N/A |
| Speed | Ethernet 10Mbps (half duplex), 20Mbps (full duplex); Fast Ethernet 100Mbps (half duplex), 200Mbps (full duplex); 100BASE-TX: 14,8800bps/port; Gigabit Ethernet 1000Mbps (half duplex), 2000Mbps (full duplex); 1000BASE-TX: 148800bps/port; 10000BASE-TX: 14880000bps/port; 10 Gigabit Ethernet 10000Mbps (half duplex), 20000Mbps |
| Cabling | 10Base-TX: Cat 5 or above (25Om); POE=250M; 100Base-TX: Cat6 UTP/100m; POE=250M; 1000Base-TX: Cat 6 UTP or above (100m) POE=250M |
| Bandwidth | 96Gb Internal Bandwidth |
| MAC Table | 16Kb |
| Auto MDI/MDIX | Yes All Ports |
| Console | Yes – Web & RS232 Layer2 Management (Telnet / SSH / CLI) |
| Transfer Pattern | Store & Forward |
| Hardware | |
| Processor Type | Realtek Industrial Type |
| LED Panel | POE Activity, Data Activity, Redundant Activity, Power Activity |
| Main Board | Double Layer |
| Case | Metal Case |
| Mounting | Rackmount / Desktop |
| PD’s | |
| IP Camera | Yes |
| IP Phone | Yes |
| (+12/1.(/6)3 | Yes |
| General | |
| Protection Rating | IP51 |
| Web Language | English |
| Dimension | 219*149*45 mm |
| Weight | 1.198 kg |
| Processor Temperature Tolerance | Up To +130°C |
| Storage Temp | -40°C ~ +95°C / 10% ~ 90% RH |
| Operation Temp | -40°C ~ +80°C / 10% ~ 90% RH |
| Radiation Electromagnetic | EN55016 |
| Power Supply | |
| Power | 200~240V AC, 50~60Hz |
| Redundant | N/A |
| LED Power | Yes |
| Power Cable | Available |
| Guarantee | |
| Product Guarantee | 3 Years Platinum Guarantee |
| MTBF | 100K hrs min. MIL-HDBK-217F (25°) |
| Camera | |
| Image Sensor | 6MP (Sony-Japan) Progressive scan CMOS Sensor (1/2.8″) |
| CPU | Dual-Core ARM Cortex-A7@900 MHz |
| Lens | 2.7-13.5 mm @ F1.6, Motorized Fast Auto Focus Lens |
| Resolution | 3200*1800 (6MP) |
| Available IR Range | 70*80 m Smart IR SMD (Osram-Germany) Technology Smart White light Technology |
| D/N Filter | IR cut filter with auto switch |
| Min Illumination | Color: 0.001 Lux(AGC on) – B/W: 0 Lux(IR on) |
| Angle of View | H-FOV: 112°~36°, V-FOV: 58°~20°, D-FOV: 120°~39° |
| Night Vision | Color / IR |
| Picture Adjust | |
| Picture Function | 120dB WDR/DWDR, 2D/3D DNR, BLC, HLC, ROI, Defog |
| Image Stabilization | Yes (EIS) |
| Shutter Speed | Manual (1/3 ~ 1/100.000), Auto |
| Image Parameter Control | Off, On, Timing (Adjust 0 ~ 255) |
| D/N Control | Timing, Auto, Color on, Color off |
| S/N | > 56dB |
| Image Parameter | Saturation, Brightness, Contrast, Sharpness, Hue |
| Video / Audio | |
| Video Compression | H.264+(Ultra H.264), H.265+ (Ultra H.265), MJPEG |
| Audio Compression | G.711A, G.711U |
| Frame Rate (60Hz) | 30fps@ 6MP(3200*1800), 30fps@ 4MP, 90fps@ 2MP |
| Transmission Stream | Triple Stream (Video Bit Rate:11 Kbps~16 Mbps) |
| Network | |
| Protocols | TCP/IP(V4, V6), ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, IGMP, UPnP, SMTP, UPnP-TM, P2P, SNMP (V1, V2, V3), UDP, NAT, Multicast, RTMP |
| Compatibility | Onvif Ver2.6, Profile S, G, T, CGI, SDK, API |
| Streaming Method | Unicast, Multicast |
| Web Viewer | IE, Edge, Firefox, Chrome |
| Function | |
| Recording | FTP, NVR, CMS, VMS, NAS, SD Card, ANR |
| Record Type | Manual, Motion Detection, Smart Detection, Schedule |
| Alarm Triggers | All Intelligent Function |
| Event Action | Email, PTZ, Snapshot, Recording, Buzzer, Pop up, Show Message, Smart Light |
| Event | Smart Motion Detection, Video Shelter |
| Intelligent Function | 13 Smart Functions, Line Crossing, Area Intrusion, Region Entrance, Region Exiting, Fast Moving, Loitering Detection, Blurred Detection, Scene Change Detection, Audio exception Detection, Smart People Counting, Face Detection, Smart People Counting, Crowd Density Monitoring, Heat Map |
| Interface | |
| Network | 1 RJ45 (10M / 100M) Ethernet Port |
| External Audio | Audio Out, Audio In |
| Internal Audio | Internal Mic |
| Alarm | Alarm In, Alarm Out |
| CVBS | N/A |
| Power | PoE LAN, DC In |
| Reset Button | Yes (Optional) |
| Memory Slot | Yes – Micro SD/SDHC/SDXC Slot (256 Gb Max) (ANR Support) |
| General | |
| Protection Rating | IP67, IK10, 6KV Surge Protection |
| Power Supply | DC12V ± 10% |
| POE Supply | IEEE802.3af – Max 13 Watt |
| Web Language | English, Persian |
| Dimension | 265*100 mm |
| Weight | 1.4 kg |
| Operation Humidity | Humidity 95% or less (non-condensing) |
| Operation Temp | -30°C ~ +60°C |
| Guarantee | |
| Product Guarantee | 5 Years Gold Guarantee |
| MTBF | 100K hrs min. MIL-HDBK-217F (25°) |
| Certificates | EN, CN, FCC, CFR |
“`
