NC-CUPRUM-6SFTPO-LSZH
کابل شبکه NC-CUPRUM-6SFTPO-LSZH
| NC-Cuprum 6SFTPI-LSZH | |
|---|---|
| Conductor | |
| Size | 23 AWG |
| Design Type | Spacer / Copper Wires / 1 Jacket / Shield / Foil |
| Diameter (mm) | 0.5 ± 0.05 |
| Insulation | |
| Type | SFTP Indoor |
| Cable Diameter | Nom. 5.5 ± 0.5 mm |
| Jacket Thickness | Nominal Thickness = 0.56 mm |
| Shielding | Aluminium / Polyester Foil |
| Physical | |
| 1. Cold Bend Test | -30 ± 2°C × 4 hrs no crack |
| 2. Dielectric Strength | AC 1.7KV for 2s |
| Jacket | |
| Min Bending Radius | 50 mm |
| Installation Temperature | -20°C to +65°C |
| Jacket Type | |
| Type | Low Smoke Zero Halogen (LSZH) |
| Overall Diameter | 8.1 ± 0.3 mm |
