| CPU & GPU Capabilities | |
| CPU | Quad-Core ARM Cortex-A76 & Quad-Core ARM Cortex-A55 |
| GPU | ARM Mali-G610MC4 |
| IP Channel Input | 32CH x 8K/30fps (Up to 32MP Supported) |
| Video & Audio | |
| Video Output Mode | 4CH HDMI video output, 2CH VGA Simultaneous mode max. resolution of HDMI1 is 8K max. resolution of HDMI2 HDMI3 HDMI4 is 4K Heterogeneous mode Simultaneous Video source Output for VGA1 and HDMI4, Simultaneous Video source Output for VGA2 and HDMI2 max. resolution of HDMI1 HDMI3 and HDMI4 is 4K max. resolution of HDMI2 is 1080P |
| Output1 HDMI | 7680 x 4320/30Hz, 3840 x 2160/30Hz, 1920 x 1080/60Hz |
| Output2 HDMI | 3840x 2160/30Hz, 1920 x1080/60Hz, 1280 x1024/60Hz |
| Output3 HDMI | 1920 x 1080/60Hz, 1280 x1024/60Hz, 1280 x720/60Hz |
| Output4 HDMI | 3840x 2160/30Hz, 1920 x1080/60Hz, 1280 x1024/60Hz |
| Output1 VGA | 1920 x 1080/60Hz, 1280 x1024/60Hz, 1280 x720/60Hz |
| Output2 VGA | 1920 x 1080/60Hz, 1280 x1024/60Hz, 1280 x720/60Hz |
| Main/Secondary Screen Split | 1.4.8.9.16.25.36.64 screen split |
| Audio Output | 2CH, RCA |
| Video Compression | H.264+(Ultra H.264), H.265+(Ultra H.265) Smart Event Codec |
| Audio Compression | G.711A, G.711U |
| Video Resolution | 32MP, 16MP, 12MP, 8MP, 5MP, 4MP, 3MP, 1080P, 720P, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF |
| Input Bandwidth | 1024Mbps or 512 Mbps (when RAID is enabled) |
| Record Mode | Manual, Schedule, Alarm, Event, Smart Event |
| Failover | N+1 Hot Spare |
| Pre & Post Record | Pre 1~30 sec, Post 10~300 sec |
| Playback & Backup | |
| Decoding Capability | H.265 32CH 1080P@30fps 16CH 4MP@30fps 8CH 8MP@30fps 4CH 16MP@30fps 2CH 32MP@30fps |
| Sync Playing Capability | 1CH 32MP@30fps 2CH 16MP@30fps 4CH 8MP@30fps 8CH 4MP@30fps 16CH 1080P@30fps |
| Search Mode | Time & Date, Motion , Alarm Input, AI Function |
| Playback | Normal, Time Division, Label, Event, Picture Playback, Smart Playback, ANR Support |
| Backup Mode | USB Device, Network, Internal Sata Burner, Cloud Storage |
| Network & Monitoring | |
| Protocols | HTTPS, HTTP, TCP/IP V4/V6, ICMP, RTSP, UDP, NTP, DHCP, DDNS, FTP, SNMP V1-V2-V3, UPnP, P2P, NAT, Multi Cast Onvif Ver2.6, Profiles S,G,T, CGI, SDK, API |
| Compatibility | Onvif Ver2.6, Profiles S, G, T, CGI, SDK, API |
| Output Bandwidth | 800Mbps or 400 Mbps (when RAID is enabled) |
| User | 32 Users |
| Streaming Method | Unicast, Multicast |
| Web Viewer | IE, Edge, Firefox, Chrome |
| Software | Unlimited KDT CMS/VMS |
| Smart Device | iOS, Android Phone & Tablet |
| Hard Disk | |
| HDD | 8 Sata HDD With Cage (Hot Swap Technology) |
| Capacity | Up To 22 TB For Each HDD |
| Raid Support | Raid 0-1-5-10 |
| Group HDD | Yes |
| External Interface | |
| Network | 2xRJ45, 2x5GE Or 2x self-adaptive Ethernet interface, (10/100/1000Mbps)+LED Indicator |
| 4G Dongle / Wifi | Supported |
| USB Interface | Front Panel: 2 x USB 2.0 / Rear Panel: 2 x USB 3.0 |
| eSATA | 1 |
| Alarm In/Alarm Out | 16 / 8 |
| Controller | 1 x RS-485 Interface / 1 x RS-232 |
| 12V Out | 1 |
| Smart Function | |
| Intelligent Function | 20 Smart Function Line Crossing, Area Intrusion, Face Detection, Audio Exception Detection, Unattended Objects, Object Missing, Region Entrance, Region Exiting, Fast Moving, Loitering Detection, People Gathering Detection, Parking Detection, Blurred Detection, Scene Change Detection, Car Shape Detection, People Counting, Video Shelter, Motion Detection, Human Detection, Car Detection |
| General | |
| Power Supply | 200~240V AC,50~60Hz |
| Power Consumption | <30 W Without Hard Disk |
| Power redundant | N/A |
| Working Environment | -20°C ~+50°C /10% ~ 90% RH (Non condensing) |
| Rackmount | Yes 2 Unit |
| Dimension (WxDxH) | 440*450*90 mm |
| Weight(Without HDD) | 7.3 Kg |
| Guarantee | |
| Product Guarantee | 3 Years Platinum Guarantee |
| MTBF | 100K hrs min. MIL-HDBK-217F (25°) |
