| Camera |
| Image Sensor | 8MP (Sony-Japan) Progressive scan Cmos Sensor (1/2.8″) |
| CPU | Dual-Core ARM Cortex-A7 @900 MHz |
| Lens | 3.6 mm fixed Lens @F1.6 |
| Resolution | 3840*2160 (8MP) |
| Available IR Range | 30 m Smart IR SMD Technology (Oram-German) / 30 m Warm Light Technology (1 pcs IR SMD) |
| D/N Filter | IR cut filter with auto switch |
| Min Illumination | Color: 0.001 Lux (AGC on) / B-W: 0.0 Lux (IR on) |
| Angle of View | H-FOV: 89°, V-FOV: 47°, D-FOV: 90° |
| Night Vision | Color / IR |
| Picture Adjust | 120dB WDR/DWDR, 2D/3D DNR, BLC, HLC, ROI, Defog, Rotate |
| Shutter Speed | Manual (1/3 ~ 1/10,000), Auto |
| Image Parameter Control | Off, On, Timing (Adjust 0 ~ 255) |
| D/N Control | Timing, Auto, Color on, Color off |
| S/N | > 56dB |
| Image Parameter | Saturation, Brightness, Contrast, Sharpness, Hue |
| Video / Audio |
| Video Compression | H.264 (Ultra H.264), H.265 (Ultra H.265) |
| Audio Compression | G.711A, G.711U |
| Frame Rate (60Hz) | 30fps@ 8MP (3840*2160), 20fps@ 6MP, 30fps@ 4MP, 30fps@ 2MP |
| Transmission Stream | Triple Stream (Video Bit Rate: 11 Kbps ~ 13 Mbps) |
| Network |
| Protocols | TCP/IPv4, vs, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, UPnP-TM, P2P, Bonjour, SNMPv1/v2/v3, UDP, NAT, Multicast, RTMP |
| Compatibility | Onvif Ver2.6, Profile S, G, T, CGI, SDK, API |
| Streaming Method | Unicast, Multicast |
| Web Viewer | IE, Edge, Firefox, Chrome |
| Smart Device | iOS, Android Phone & Tablet |
| Function |
| Recording | FTP, NVR, CMS, VMS, SD Card, ANR |
| Record Type | Manual, Motion Detection, Smart Detection, Schedule |
| Alarm Triggers | All Intelligent Function |
| Event Action | Email, PTZ, Snapshot, Recording, Buzzer, Pop up, Show Message, Smart Light |
| Event | Motion Detection, Video Shelter |
| Intelligent Function | 8 Smart Function |
| Interface |
| Network | 1 RJ45 (10M / 100M) Ethernet Port |
| External Audio | Audio Out, Audio In |
| Internal Audio | Internal Mic |
| Alarm | Alarm In, Alarm Out |
| CVBS | N/A |
| Power | PoE LAN, DC In |
| Reset Button | Yes (Optional) |
| Memory Slot | Yes – Micro SD/SDHC/SDXC Slot (256 Gb Max) (ANR Support) |
| General |
| Protection Rating | IP67, 6KV Surge Protection |
| Power Supply | DC12V ± 10% |
| PoE Supply | IEEE802.3af – Max 11 Watt |
| Web Language | English, Persian |
| Dimension | 275*102 mm |
| Weight | 1.2 Kg |
| Operation Humidity | Humidity 95% or less (non-condensing) |
| Operation Temp | -30°C ~ +60°C |
| Guarantee |
| Product Guarantee | 5 Years Gold Guarantee |
| MTBF | 100k hrs min. MIL-HDBK-217F (25°) |
| Certificates | EN, CN, FCC, CFR |
